Hei-TORQUE Ultimate 100
P/N: 036093090
The devices of the Hei-TORQUE Ultimate line are Heidolph high performance overhead stirrers.
The Hei-TORQUE Ultimate 100 is a overhead stirrer with a wide speed range (10 - 2,000 rpm) and a maximum torque of 100 Ncm. It can powerfully stir viscosities up to 60,000 mPas or volumes up to 50 liters (H2O).
In addition, the Hei-TORQUE Ultimate 100 offers, above all, the possibility of ramp programming, process monitoring (including timer function, torque trend display as a value), as well as the necessary equipment for documenting your application parameters. For this it is equipped with two interfaces - USB and RS232 - which give you the greatest flexibility to connect the device to a PC, a programmable logic controller (PLC) or an automation system such as e.g. LabManager. The scope of delivery includes the free Hei-Control software for remote control of up to 4 devices via PC.
The overhead stirrer Hei-TORQUE Ultimate 100 performs every stirring task with minimal noise thanks to the latest engine technology. The safety-related start/stop touch-function serves to minimize the risk of unintentional switching on.
Suitable for use in fume hoods or as a drive for reactor superstructures, the Hei-TORQUE Ultimate 100 has a quick-action chuck (quick chuck with safety ring) with a diameter of 10.5 mm, which can be combined with a large number of stirring tools.
Connectivity
The integrated RS232/USB interface allows seamless integration in a laboratory software and in automated process solutions. Remote control and data logging are therefore easy and fast to realize.
Controllable start-up
After having switched on the device, the start-up intensity is adjustable from soft to fast. This is how the perfect application-specific parameter can be chosen to ensure an optimal performance and to prevent liquid from splashing at the start.
Change of rotational direction
The rotational direction of the device can be selected clockwise and counterclockwise. Through the flow variation, suspensions can be stirred up easily and dissolution processes can be accelerated.
Technical Data
